Sword Track 48V
Sword Track 48V is an AVOLUX LED lighting fixture in the 48V Series category with a power of 5W - 15W and IP20 protection.
Product icons
| Input Voltage | 48V DC |
|---|---|
| Wattage | 5W - 15W |
| Protection Class | IP20 |
| Shape | Linear |
| Optical | Lens |
| width, height | 23x25mm |
DESCRIPTION
-- Aluminum profile body.
-- With 48V DC input.
-- Intelligent cooling design with passive cooling technology.
-- With DC/DC transformer adapter suitable for Stucchi 48V rail system.
-- Lens optics with narrow, medium and oval angle light distributions.
-- DALI and 1-10V DIM options available.
-- Wireless DIM and Hot DIM, which are high-tech control systems
applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
-- High CRI>90 and standard CRI>80 LED options are available.
-- High color compatibility: <3 SDCM.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 15W | CRI>80 | I02. LL.15115 . (..) . (...) . (..) . (..) . (....) | 2700K | 1215 |
| 3000K | 1253 | |||
| 4000K | 1290 | |||
| 5000K | 1328 | |||
| CRI>90 | I02. LL.15115 . (..) . (...) . (..) . (..) . (....) | 2700K | 1130 | |
| 3000K | 1163 | |||
| 4000K | 1200 | |||
| 5000K | 1234 |
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 10W | CRI>80 | I02. LL.15115 . (..) . (...) . (..) . (..) . (....) | 2700K | 810 |
| 3000K | 835 | |||
| 4000K | 860 | |||
| 5000K | 885 | |||
| CRI>90 | I02. LL.15115 . (..) . (...) . (..) . (..) . (....) | 2700K | 753 | |
| 3000K | 775 | |||
| 4000K | 800 | |||
| 5000K | 823 |
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 5W | CRI>80 | I02. LL.15115 . (..) . (...) . (..) . (..) . (....) | 2700K | 405 |
| 3000K | 417 | |||
| 4000K | 430 | |||
| 5000K | 442 | |||
| CRI>90 | I02. LL.15115 . (..) . (...) . (..) . (..) . (....) | 2700K | 376 | |
| 3000K | 387 | |||
| 4000K | 400 | |||
| 5000K | 411 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | 6 | Length | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15 | 15W - 350mA | 827 | CRI>80 - 2700K | 927 | CRI>90 - 2700K |  | SP | 20° - Spot |  | 01 | white | 889mm | |
| 10 | 10W - 350mA | 830 | CRI>80 - 3000K | 930 | CRI>90 - 3000K |  | M.E. | 38° - Medium |  | 02 | ral 9010 | 594mm | |
| 5 | 5W - 350mA | 840 | CRI>80 - 4000K | 940 | CRI>90 - 4000K |  | OV | 21° x 43° - Oval |  | 03 | black | 299mm | |
| 850 | CRI>80 - 5000K | 950 | CRI>90 - 5000K |  | 04 | gray | |||||||
 | 05 | dark gray | |||||||||||
 | 06 | special color |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
- Length
Frequently Asked Questions
What is the wattage of Sword Track 48V?
Sword Track 48V has a power of 5W - 15W.
What is the protection class of Sword Track 48V?
The protection class of Sword Track 48V is IP20.
Which certifications and standards does Sword Track 48V have?
Sword Track 48V carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class III, IP20.
What is the product code of Sword Track 48V?
The product (stock) code of Sword Track 48V is I02.LL.15115.
Where can I download the catalog or PDF of Sword Track 48V?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/214-215.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/48V/SWORD%2048V%20Tracklight.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/I02.LL.15115.rar) buttons on this page.
