Silindir Pendant 40
Silindir Pendant 40 is an AVOLUX LED lighting fixture in the 48V Series category with a power of 5W and IP20 protection.
Product icons
| Input Voltage | 48V DC |
|---|---|
| Wattage | 5W |
| Protection Class | IP20 |
| Shape | Cylinder |
| Optical | Reflector |
DESCRIPTION
-- Aluminum profile body.
-- Intelligent cooling design with passive cooling technology.
-- With DC/DC transformer adapter suitable for Stucchi 48V rail system.
-- Steel pendant wire up to 5.00m long.
-- Tempered glass.
-- Classic 1-10V and DALI DIM options can be applied.
-- Wireless DIM and Hot DIM, which are high-tech control systems
applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
--Honeycomb Filter, Color Filter, Anti-Glare and Viewfinder accessories
options can be applied.
-- Narrow, Medium and Very Wide reflector angle options are available.
-- Efficiency up to 71lm/W.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 5W | CRI>90 | I01.MLP.91202 . (..) . (...) . (..) . (..) . (....) | 2700K | 335 |
| 3000K | 342 | |||
| 3500K | 349 | |||
| 4000K | 356 | |||
| 5000K | X | |||
| CRI>98 | I01.MLP.91202 . (..) . (...) . (..) . (..) . (....) | 2700K | 258 | |
| 3000K | 263 | |||
| 4000K | 274 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | 6 | Length | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5 | 5W - 100mA | 927 | CRI>90 - 2700K | 9827 | CRI>98 - 2700K |  | M.E. | 30° - Medium |  | 01 | white | 720mm | |
| 930 | CRI>90 - 3000K | 9830 | CRI>98 - 3000K |  | FL | 40° - Flood |  | 02 | ral 9010 | 540mm | |||
| 935 | CRI>90 - 3500K | 9840 | CRI>98 - 4000K |  | W.F. | 60° - Wide Flood |  | 03 | black | 360mm | |||
| 940 | CRI>90 - 4000K |  | 04 | gray | 180mm | ||||||||
 | 05 | dark gray | |||||||||||
 | 06 | special color |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
- Length
Frequently Asked Questions
What is the wattage of Silindir Pendant 40?
Silindir Pendant 40 has a power of 5W.
What is the protection class of Silindir Pendant 40?
The protection class of Silindir Pendant 40 is IP20.
Which certifications and standards does Silindir Pendant 40 have?
Silindir Pendant 40 carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class III, IP20.
What is the product code of Silindir Pendant 40?
The product (stock) code of Silindir Pendant 40 is I01.MLP.91202.
Where can I download the catalog or PDF of Silindir Pendant 40?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/228-229.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/48V/SILINDIR%20PENDANT%2048V.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/silindir%20Pendant%2040I01.MLP.%2091202.rar) buttons on this page.
