Panda Micro
Panda Micro is an AVOLUX LED lighting fixture in the Floodlight Series category with a power of 5W and IP66 protection.
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 5W |
| Protection Class | IP66 |
| Shape | Projector |
| Optical | Lens |
-- LED projector fixture with symmetrical light output.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 5W | CRI>80 | O07.WL.00528 . (..) . (...) . (..) . (..) | 2700K | 519 |
| 3000K | 525 | |||
| 3500K | 549 | |||
| 4000K | 562 | |||
| 5000K | 568 | |||
| 6500K | 574 | |||
| 6W | CRI>80 | O07.WL.00528 . (..) . (...) . (..) . (..) | Red | 340 |
| 7W | CRI>80 | O07.WL.00528 . (..) . (...) . (..) . (..) | Green | 520 |
| 7W | CRI>80 | O07.WL.00528 . (..) . (...) . (..) . (..) | Blue | 257 |
| 7W | CRI>80 | O07.WL.00528 . (..) . (...) . (..) . (..) | Amber | 625 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 5 | 5W - 700mA | 827 | CRI>80 - 2700K | 625 | Red |  | SP | 14° - Spot |  | 01 | white |
| 830 | CRI>80 - 3000K | 525 | Green |  | M.E. | 25° - Medium |  | 02 | ral 9010 | ||
| 835 | CRI>80 - 3500K | 470 | Blue |  | M.F. | 30° - Medium Flood |  | 03 | black | ||
| 840 | CRI>80 - 4000K | 590 | Amber |  | FL | 45° - Flood |  | 04 | gray | ||
| 850 | CRI>80 - 5000K |  | OV | 40° x 18° - Oval |  | 05 | dark gray | ||||
| 865 | CRI>80 - 6500K |  | 06 | special color | |||||||
1- Product code / Armature code
2- Power
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Panda Micro?
Panda Micro has a power of 5W.
What is the protection class of Panda Micro?
The protection class of Panda Micro is IP66.
Which certifications and standards does Panda Micro have?
Panda Micro carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, Protection class II, IP66, IK08.
What is the product code of Panda Micro?
The product (stock) code of Panda Micro is O07.WL.00528.
Where can I download the catalog or PDF of Panda Micro?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/355.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/Projekt%C3%B6r/Panda.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/outdoor/PANDA%20M%C4%B0CRO.zip) buttons on this page.
