Prozoom Mini
Prozoom Mini is an AVOLUX LED lighting fixture in the Floodlight Series category with a power of 10W and IP65 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 10W |
| Protection Class | IP65 |
| Shape | Projector |
| Optical | Lens |
DESCRIPTION
-- LED projector fixture with symmetrical light output.
-- Body made of corrosion-resistant aluminum injection raw material.
-- It has a bracketed mounting system.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design.
-- With optical lens adjustable from narrow angle to wide angle.
-- 2700K, 3000K, 3500K, 4000K and 5000K color temperature options are available.
-- IP protection is provided without any problems with silicone gaskets.
-- All external screws are stainless.
-- Corrosion and salt resistant thanks to double-layer polyester powder paint.
-- High color compatibility: <3 SDCM
-- Stainless cable gland is used in the luminaire and 220V main
The mains cable has an IP68 protected connector. with this
inside the product by using the 220V cable end and the water stopper between the armature.
Humidification and water vapor formation are minimized.
-- Mechanical locking system.
-- DALI and 1-10V Dim options are available.
-- L80 B10 50000 hours and five years warranty.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 10W | CRI>80 | O07.WL.00824 . (..) . (...) . (..) . (..) | 2700K | 703 |
| 3000K | 717 | |||
| 3500K | 731 | |||
| 4000K | 746 | |||
| 5000K | 761 | |||
| 6500K | X | |||
| CRI>90 | O07.WL.00824 . (..) . (...) . (..) . (..) | 2700K | 657 | |
| 3000K | 670 | |||
| 3500K | 683 | |||
| 4000K | 697 | |||
| 5000K | X | |||
| 6500K | X |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 10 | 10W | 827 | CRI>80 - 2700K | 927 | CRI>90 - 2700K |  | SP | 21° - Spot |  | 01 | white |
| 830 | CRI>80 - 3000K | 930 | CRI>90 - 3000K |  | M.E. | 28° - Medium |  | 02 | ral 9010 | ||
| 835 | CRI>80 - 3500K | 935 | CRI>90 - 3500K |  | FL | 35° - Flood |  | 03 | black | ||
| 840 | CRI>80 - 4000K | 940 | CRI>90 - 4000K |  | W.F. | 45° - Wide Flood |  | 04 | gray | ||
| 850 | CRI>80 - 5000K |  | 05 | dark gray | |||||||
 | 06 | special color | |||||||||
1- Product code / Armature code
2- Power
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Prozoom Mini?
Prozoom Mini has a power of 10W.
What is the protection class of Prozoom Mini?
The protection class of Prozoom Mini is IP65.
Which certifications and standards does Prozoom Mini have?
Prozoom Mini carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IP66, IK07.
What is the product code of Prozoom Mini?
The product (stock) code of Prozoom Mini is O07.WL.00824.
Where can I download the catalog or PDF of Prozoom Mini?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/downloads/outdoor/Prozoom%20Mini%20O07.WL.00824.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/outdoor/Prozoom.pdf) buttons on this page.
