Line Bay
Line Bay is an AVOLUX LED lighting fixture in the High Bay Series category with a power of 200W and IP65 protection.
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 200W |
| Protection Class | IP65 |
| Shape | Stalactite |
| Optical | Lens |
-- LED high ceiling fixture with symmetrical light output.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 200W | CRI>70 | O07.WL.19210 . (..) . (...) . (..) . (..) | 2700K | 20134 |
| 3000K | 20458 | |||
| 3500K | 21398 | |||
| 4000K | 21868 | |||
| 5000K | 22104 | |||
| 6500K | 22340 | |||
| CRI>80 | O07.WL.19210 . (..) . (...) . (..) . (..) | 2700K | 20024 | |
| 3000K | 20256 | |||
| 3500K | 21196 | |||
| 4000K | 21652 | |||
| 5000K | 21884 | |||
| 6500K | 22118 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 200 | 200W - 470mA | 727 | CRI>70 - 2700K | 827 | CRI>80 - 2700K |  | FL | 65° - Flood |  | 01 | white |
| 150 | 150W - 365mA | 730 | CRI>70- 3000K | 830 | CRI>80 - 3000K |  | W.F. | 78° - Wide Flood |  | 02 | ral 9010 |
| 735 | CRI>70- 3500K | 835 | CRI>80 - 3500K |  | ASM | Asymmetric |  | 03 | black | ||
| 740 | CRI>70- 4000K | 840 | CRI>80 - 4000K |  | 04 | gray | |||||
| 750 | CRI>70- 5000K | 850 | CRI>80 - 5000K |  | 05 | dark gray | |||||
| 765 | CRI>70 - 6500K | 865 | CRI>80 - 6500K |  | 06 | special color | |||||
1- Product code / Armature code
2- Power
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Line Bay?
Line Bay has a power of 200W.
What is the protection class of Line Bay?
The protection class of Line Bay is IP65.
Which certifications and standards does Line Bay have?
Line Bay carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IK08, IP65.
What is the product code of Line Bay?
The product (stock) code of Line Bay is O07.WL.19210.
Where can I download the catalog or PDF of Line Bay?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/441.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/Y%C3%BCksek%20Tavan/Line%20Bay.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/outdoor/O07.WL.19210.zip) buttons on this page.
