Canopy Highbay
Canopy Highbay is an AVOLUX LED lighting fixture in the High Bay Series category with a power of 250-350W and IP65 protection.
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 250-350W |
| Protection Class | IP65 |
| Shape | surface mounted |
| Optical | Lens |
-- LED high ceiling fixture with symmetrical light output.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 350W | CRI>70 | O07.WL.16204 . (..) . (...) . (..) . (..) | 2700K | 44998 |
| 3000K | 45716 | |||
| 3500K | 47818 | |||
| 4000K | 48870 | |||
| 5000K | 49396 | |||
| 6500K | 49924 | |||
| CRI>80 | O07.WL.16204 . (..) . (...) . (..) . (..) | 2700K | 44748 | |
| 3000K | 45264 | |||
| 3500K | 47344 | |||
| 4000K | 48386 | |||
| 5000K | 48904 | |||
| 6500K | 49428 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 350 | 350W - 675mA | 727 | CRI>70 - 2700K | 827 | CRI>80 - 2700K |  | SS | 17° - Super Spot |  | 01 | white |
| 300 | 300W - 590mA | 730 | CRI>70- 3000K | 830 | CRI>80 - 3000K |  | SP | 32° - Spot |  | 02 | ral 9010 |
| 250 | 250W - 495mA | 735 | CRI>70- 3500K | 835 | CRI>80 - 3500K |  | M.E. | 52° - Medium |  | 03 | black |
| 740 | CRI>70- 4000K | 840 | CRI>80 - 4000K |  | FL | 65° - Flood |  | 04 | gray | ||
| 750 | CRI>70- 5000K | 850 | CRI>80 - 5000K |  | W.F. | 98° - Wide Flood |  | 05 | dark gray | ||
| 765 | CRI>70 - 6500K | 865 | CRI>80 - 6500K |  | OV | 30° x 110° - Oval |  | 06 | special color | ||
 | ASM | Asymmetric |
1- Product code / Armature code
2- Power
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Canopy Highbay?
Canopy Highbay has a power of 250-350W.
What is the protection class of Canopy Highbay?
The protection class of Canopy Highbay is IP65.
Which certifications and standards does Canopy Highbay have?
Canopy Highbay carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IP66, IK08.
What is the product code of Canopy Highbay?
The product (stock) code of Canopy Highbay is O07.WL.16204.
Where can I download the catalog or PDF of Canopy Highbay?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/449.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/Y%C3%BCksek%20Tavan/Canopy%20Highbay.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/outdoor/O07.WL.16204.zip) buttons on this page.
