Flatbay
Flatbay is an AVOLUX LED lighting fixture in the High Bay Series category with a power of 150W and IP65 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 150W |
| Protection Class | IP65 |
| Shape | surface mounted |
| Optical | Lens |
DESCRIPTION
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 150W | CRI>70 | O07.WL.16250 . (..) . (...) . (..) . (..) | 2700K | 23908 |
| 3000K | 24386 | |||
| 3500K | 24874 | |||
| 4000K | 25371 | |||
| 5000K | 25878 | |||
| 6500K | 26396 | |||
| CRI>80 | O07.WL.16250 . (..) . (...) . (..) . (..) | 2700K | 22137 | |
| 3000K | 22589 | |||
| 3500K | 23050 | |||
| 4000K | 23520 | |||
| 5000K | 24000 | |||
| 6500K | 24480 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 150 | 150W | 727 | CRI>70 - 2700K | 827 | CRI>80 - 2700K |  | FL | 80° - Flood |  | 01 | white |
| 730 | CRI>70- 3000K | 830 | CRI>80 - 3000K |  | W.F. | 110° - Wide Flood |  | 02 | ral 9010 | ||
| 735 | CRI>70- 3500K | 835 | CRI>80 - 3500K |  | 03 | black | |||||
| 740 | CRI>70- 4000K | 840 | CRI>80 - 4000K |  | 04 | gray | |||||
| 750 | CRI>70- 5000K | 850 | CRI>80 - 5000K |  | 05 | dark gray | |||||
| 765 | CRI>70 - 6500K | 865 | CRI>80 - 6500K |  | 06 | special color | |||||
1- Product code / Armature code
2- Power / Güç
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Flatbay?
Flatbay has a power of 150W.
What is the protection class of Flatbay?
The protection class of Flatbay is IP65.
Which certifications and standards does Flatbay have?
Flatbay carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IK08, IP65.
What is the product code of Flatbay?
The product (stock) code of Flatbay is O07.WL.16250.
Where can I download the catalog or PDF of Flatbay?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/443.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/Y%C3%BCksek%20Tavan/Flatbay.pdf) buttons on this page.
