Cubicline Surface Mounted
Cubicline Surface Mounted is an AVOLUX LED lighting fixture in the Linear Profile Led Series category with a power of 24-59W and IP20 protection.
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 24-59W |
| Protection Class | IP20 |
| Shape | Linear |
| Optical | diffuser |
| width, height | 36-75mm |
| Mounting Type | surface mounted |
| Length (A) | CRI | Order Code | Kelvin | 24W 250mA lm | 34W 350mA lm |
|---|---|---|---|---|---|
| 1145mm | CRI>80 | I02.LL.19446 . (...) . (...) . (...) . (...) | 2700K | 2419 | 3394 |
| 3000K | 2496 | 3502 | |||
| 3500K | 2535 | 3556 | |||
| 4000K | 2633 | 3694 | |||
| 5000K | 2670 | 3746 | |||
| CRI>90 | I02.LL.19446 . (...) . (...) . (...) . (...) | 2700K | 2031 | 2850 | |
| 3000K | 2089 | 2932 | |||
| 3500K | 2128 | 2986 | |||
| 4000K | 2205 | 3095 |
| Length (A) | CRI | Order Code | Kelvin | 30W 250mA lm | 42W 350mA lm |
|---|---|---|---|---|---|
| 1425mm | CRI>80 | I02.LL.19446 . (...) . (...) . (...) . (...) | 2700K | 3082 | 4274 |
| 3000K | 3180 | 4410 | |||
| 3500K | 3229 | 4479 | |||
| 4000K | 3354 | 4652 | |||
| 5000K | 3401 | 4717 | |||
| CRI>90 | I02.LL.19446 . (...) . (...) . (...) . (...) | 2700K | 2588 | 3589 | |
| 3000K | 2662 | 3692 | |||
| 3500K | 2712 | 3761 | |||
| 4000K | 2810 | 3897 |
| Length (A) | CRI | Order Code | Kelvin | 36W 250mA lm | 51W 350mA lm |
|---|---|---|---|---|---|
| 1705mm | CRI>80 | I02.LL.19446 . (...) . (...) . (...) . (...) | 2700K | 3768 | 5289 |
| 3000K | 3888 | 5457 | |||
| 3500K | 3949 | 5542 | |||
| 4000K | 4101 | 5756 | |||
| 5000K | 4159 | 5837 | |||
| CRI>90 | I02.LL.19446 . (...) . (...) . (...) . (...) | 2700K | 3164 | 4442 | |
| 3000K | 3255 | 4569 | |||
| 3500K | 3316 | 4654 | |||
| 4000K | 3436 | 4822 |
| Length (A) | CRI | Order Code | Kelvin | 42W 250mA lm | 59W 350mA lm |
|---|---|---|---|---|---|
| 1985mm | CRI>80 | I02.LL.19446 . (...) . (...) . (...) . (...) | 2700K | 4478 | 6233 |
| 3000K | 4620 | 6431 | |||
| 3500K | 4692 | 6531 | |||
| 4000K | 4873 | 6784 | |||
| 5000K | 4942 | 6879 | |||
| CRI>80 | I02.LL.19446 . (...) . (...) . (...) . (...) | 2700K | 3760 | 5234 | |
| 3000K | 3868 | 5384 | |||
| 3500K | 3940 | 5485 | |||
| 4000K | 4083 | 5683 |
| 2 | Length (A) | 3 | Watts - Driving Current | 4 | CRI/Kelvin | 4 | CRI/Kelvin | 5 | Product Color | |
|---|---|---|---|---|---|---|---|---|---|---|
| 1145mm | 24W | 24W (Direct) - 250mA | 827 | CRI>80 - 2700K | 927 | CRI>90 - 2700K |  | 01 | white | |
| 34W | 34W (Direct) - 350mA | |||||||||
| 1425mm | 30W | 30W (Direct) - 250mA | 830 | CRI>80 - 3000K | 930 | CRI>90 - 3000K |  | 02 | ral 9010 | |
| 42W | 42W (Direct) - 350mA | |||||||||
| 1705mm | 36W | 36W (Direct) - 250mA | 835 | CRI>80 - 3500K | 935 | CRI>90 - 3500K |  | 03 | black | |
| 51W | 51W (Direct) - 350mA | |||||||||
| 1985mm | 42W | 42W (Direct) - 250mA | 840 | CRI>80 - 4000K | 940 | CRI>90 - 4000K |  | 04 | gray | |
| 59W | 59W (Direct) - 350mA | |||||||||
| 850 | CRI>80 - 5000K |  | 05 | dark gray | ||||||
 | 06 | special color |
1- Product code / Armature code
2- Length
3- Power
4- CRI / Kelvin
5- Color / Product color
6- Control type
Frequently Asked Questions
What is the wattage of Cubicline Surface Mounted?
Cubicline Surface Mounted has a power of 24-59W.
What is the protection class of Cubicline Surface Mounted?
The protection class of Cubicline Surface Mounted is IP20.
Which certifications and standards does Cubicline Surface Mounted have?
Cubicline Surface Mounted carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, IP20.
What is the product code of Cubicline Surface Mounted?
The product (stock) code of Cubicline Surface Mounted is I02.LL.19446.
Where can I download the catalog or PDF of Cubicline Surface Mounted?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/linealed/238.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/linealedpanel/CUBICLINE%20Linea%20Led.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/linea/I02.LL.19446.rar) buttons on this page.
