Tengri
Tengri is an AVOLUX LED lighting fixture in the Solar Fixtures Series category with a power of 8W and IP65 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 8W |
| Protection Class | IP65 |
| Shape | Pole Mounted |
| Optical | Symmetrical Very Wide Angle Illumination Lens |
DESCRIPTION
| Armature Data | |
|---|---|
| Product Code | O07.ST.09115.8.740.05 |
| Family Name | Tengri |
| Material | Aluminum Injection |
| LED Life | L70/B50 50000h |
| Optical | Symmetrical Very Wide Angle Illumination Lens |
| PV Panel Power | 20W |
| Panel Type | MonoCrystal |
| Solar Panel Voltage | 5V |
| Armature Power | 8W |
| Number of LEDs | 80 Pieces |
| Lumen | 1000lm |
| Luminaire Efficiency | 125lm/W |
| CRI | 70 |
| Battery Power | 64W |
| Battery Voltage | 3.2V |
| Battery Current | 20A |
| Battery Type | LiFePO4 |
| Cloudy Day Working Time | 12 hours |
| Operating Temperature | -20°C / +50°C |
| Protection | IP65 |
| Quasar Mini Solar | |
|---|---|
| System Power | 8W |
| Armature Output Lumen CRI>70 | 4000K | 1000lm |
| Max. Mast Span (a) | 10m |
| Max. Mast Height (h) | 4m |
| Max. Road Width (L) | - |
| Lighting Class | - |
Frequently Asked Questions
What is the wattage of Tengri?
Tengri has a power of 8W.
What is the protection class of Tengri?
The protection class of Tengri is IP65.
Which certifications and standards does Tengri have?
Tengri carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class III, IK08, IP65.
What is the product code of Tengri?
The product (stock) code of Tengri is O07.ST.09115.
Where can I download the catalog or PDF of Tengri?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/208-209.pdf) buttons on this page.
