Sword Pendant 48V
Sword Pendant 48V is an AVOLUX LED lighting fixture in the 48V Series category with a power of 5W - 15W and IP20 protection.
Product icons
| Input Voltage | 48V DC |
|---|---|
| Wattage | 5W - 15W |
| Protection Class | IP20 |
| Shape | Linear |
| Optical | Opal Diffuser |
| width, height | 23x25mm |
DESCRIPTION
-- Aluminum profile body.
-- With 48V DC input.
-- Intelligent cooling design with passive cooling technology.
-- With DC/DC transformer adapter suitable for Stucchi 48V rail system
-- With Opal Diffuser
-- DALI and 1-10V DIM options available.
-- Wireless DIM and Hot DIM, which are high-tech control systems
applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
-- High CRI>90 and standard CRI>80 LED options are available.
-- High color compatibility: <3 SDCM
-- Steel pendant wire up to 5.00m long.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 15W | CRI>80 | I02.LL.15005 . (..) . (...) . (..) . (..) . (....) | 2700K | 1084 |
| 3000K | 1118 | |||
| 4000K | 1151 | |||
| 5000K | 1185 | |||
| CRI>90 | I02.LL.15005 . (..) . (...) . (..) . (..) . (....) | 2700K | 1008 | |
| 3000K | 1039 | |||
| 4000K | 1070 | |||
| 5000K | 1102 |
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 10W | CRI>80 | I02.LL.15005 . (..) . (...) . (..) . (..) . (....) | 2700K | 723 |
| 3000K | 745 | |||
| 4000K | 767 | |||
| 5000K | 790 | |||
| CRI>90 | I02.LL.15005 . (..) . (...) . (..) . (..) . (....) | 2700K | 672 | |
| 3000K | 692 | |||
| 4000K | 714 | |||
| 5000K | 735 |
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 5W | CRI>80 | I02.LL.15005 . (..) . (...) . (..) . (..) . (....) | 2700K | 361 |
| 3000K | 372 | |||
| 4000K | 383 | |||
| 5000K | 395 | |||
| CRI>90 | I02.LL.15005 . (..) . (...) . (..) . (..) . (....) | 2700K | 336 | |
| 3000K | 346 | |||
| 4000K | 357 | |||
| 5000K | 367 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | 6 | Length | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15 | 15W - 350mA | 827 | CRI>80 - 2700K | 927 | CRI>90 - 2700K |  | W.F. | 110° - Wide Flood |  | 01 | white | 840mm | |
| 10 | 10W - 350mA | 830 | CRI>80 - 3000K | 930 | CRI>90 - 3000K |  | 02 | ral 9010 | 560mm | ||||
| 5 | 5W - 350mA | 840 | CRI>80 - 4000K | 940 | CRI>90 - 4000K |  | 03 | black | 280mm | ||||
| 850 | CRI>80 - 5000K | 950 | CRI>90 - 5000K |  | 04 | gray | |||||||
 | 05 | dark gray | |||||||||||
 | 06 | special color |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
- Length
Frequently Asked Questions
What is the wattage of Sword Pendant 48V?
Sword Pendant 48V has a power of 5W - 15W.
What is the protection class of Sword Pendant 48V?
The protection class of Sword Pendant 48V is IP20.
Which certifications and standards does Sword Pendant 48V have?
Sword Pendant 48V carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class III, IP20.
What is the product code of Sword Pendant 48V?
The product (stock) code of Sword Pendant 48V is I02.LL.15005.
Where can I download the catalog or PDF of Sword Pendant 48V?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/204-205.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/48V/SWORD%2048V%20Tracklight.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/Sword%20Pendant%2048VI01.LL.15005.rar) buttons on this page.
