Sofia
Sofia is an AVOLUX LED lighting fixture in the High Bay Series category with a power of 170W and IP66 protection.
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 170W |
| Protection Class | IP66 |
| Shape | surface mounted |
| Optical | Lens |
-- LED high ceiling fixture with symmetrical light output.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 170W | CRI>70 | O07.WL.19215 . (..) . (...) . (..) . (..) | 2700K | 23153 |
| 3000K | 23402 | |||
| 3500K | 23900 | |||
| 4000K | 24896 | |||
| 5000K | 25169 | |||
| 6500K | 24398 | |||
| CRI>80 | O07.WL.19215 . (..) . (...) . (..) . (..) | 2700K | 22506 | |
| 3000K | 22776 | |||
| 3500K | 24115 | |||
| 4000K | 24650 | |||
| 5000K | 24918 | |||
| 6500K | 24381 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 170 | 170W - 425mA | 727 | CRI>70 - 2700K | 827 | CRI>80 - 2700K |  | M.E. | 36° - Medium |  | 01 | white |
| 730 | CRI>70- 3000K | 830 | CRI>80 - 3000K |  | FL | 55° - Flood |  | 02 | ral 9010 | ||
| 735 | CRI>70- 3500K | 835 | CRI>80 - 3500K |  | W.F. | 75° - Wide Flood |  | 03 | black | ||
| 740 | CRI>70- 4000K | 840 | CRI>80 - 4000K |  | 04 | gray | |||||
| 750 | CRI>70- 5000K | 850 | CRI>80 - 5000K |  | 05 | dark gray | |||||
| 765 | CRI>70 - 6500K | 865 | CRI>80 - 6500K |  | 06 | special color | |||||
1- Product code / Armature code
2- Power
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Sofia?
Sofia has a power of 170W.
What is the protection class of Sofia?
The protection class of Sofia is IP66.
Which certifications and standards does Sofia have?
Sofia carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IP66, IK08.
What is the product code of Sofia?
The product (stock) code of Sofia is O07.WL.19215.
Where can I download the catalog or PDF of Sofia?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/434.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/Y%C3%BCksek%20Tavan/Sofia.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/outdoor/Stad%20reflekt%C3%B6rl%C3%BC%20y%C3%BCksek%20tavan%20linear%20(%20SOF%C4%B0A).zip) buttons on this page.
