Silindir Deep Opto 55
Silindir Deep Opto 55 is an AVOLUX LED lighting fixture in the COB Led Recessed Series category with a power of 15W and IP20 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 15W |
| Protection Class | IP20 |
| Shape | built-in |
| Optical | Lens |
DESCRIPTION
-- Aluminum injection body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- Tempered glass.
-- Classic DALI, 1-10V and Phase DIM options can be applied.
-- High-tech control systems Wireless DIM, Hot DIM and
Dynamic White applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
-- Honeycomb and Color Filter, Viewfinder accessory options can be applied.
-- Very Narrow, Narrow, Medium, Wide and Very Wide lens angle options are available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LEDs.
-- Efficiency up to 112lm/W.
-- High color compatibility: <3 SDCM.
-- Emergency lighting kit system can be applied.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 15W | CRI>80 | I01.MLR.18455 . (..) . (...) . (..) . (..) | 2700K | 1349 |
| 3000K | 1377 | |||
| 3500K | 1380 | |||
| 4000K | 1382 | |||
| 5000K | 1409 | |||
| CRI>90 | I01.MLR.18455 . (..) . (...) . (..) . (..) | 2700K | 1261 | |
| 3000K | 1287 | |||
| 3500K | 1290 | |||
| 4000K | 1292 | |||
| 5000K | X | |||
| CRI>98 | I01.MLR.18455 . (..) . (...) . (..) . (..) | 2700K | 1008 | |
| 3000K | 1029 | |||
| 4000K | 1033 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 15 | 15W - 350mA | 827 | CRI>80 - 2700K | 930 | CRI>90 - 3000K |  | SS | 12° - Super Spot |  | 01 | white |
| 830 | CRI>80 - 3000K | 935 | CRI>90 - 3500K |  | SP | 16° - Spot |  | 02 | ral 9010 | ||
| 835 | CRI>80 - 3500K | 940 | CRI>90 - 4000K |  | M.E. | 26° - Medium |  | 03 | black | ||
| 840 | CRI>80 - 4000K | 9827 | CRI>98 - 2700K |  | FL | 36° - Flood |  | 04 | gray | ||
| 850 | CRI>80 - 5000K | 9830 | CRI>98 - 3000K |  | W.F. | 50° - Wide Flood |  | 05 | dark gray | ||
| 927 | CRI>90 - 2700K | 9840 | CRI>98 -4000K |  | 06 | special color |
- Armatür kodu
- Güç
- Kelvin
- Reflektör açısı
- Ürün renk
Frequently Asked Questions
What is the wattage of Silindir Deep Opto 55?
Silindir Deep Opto 55 has a power of 15W.
What is the protection class of Silindir Deep Opto 55?
The protection class of Silindir Deep Opto 55 is IP20.
Which certifications and standards does Silindir Deep Opto 55 have?
Silindir Deep Opto 55 carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, Protection class II, IP20.
What is the product code of Silindir Deep Opto 55?
The product (stock) code of Silindir Deep Opto 55 is I01.MLR.18455.
Where can I download the catalog or PDF of Silindir Deep Opto 55?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/downloads/Silindir%20Deep%20Opto%2055%20I01.MLR.18455.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/Silindir%20Deep%2055%20-%20I01.MLR.18455.rar) buttons on this page.
