Pin Spot Maxi
Pin Spot Maxi is an AVOLUX LED lighting fixture in the COB Led Recessed Series category with a power of 24W and IP44 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 24W |
| Protection Class | IP44 |
| Shape | built-in |
| Optical | Lens |
DESCRIPTION
-- Aluminum injection body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- Classic DALI, 1-10V and Phase DIM options can be applied.
-- High-tech control systems Wireless DIM, Hot DIM and
Dynamic White applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
-- Medium Lens angle option is available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LED
options are available.
-- Efficiency up to 116lm/W.
-- High color compatibility: <3 SDCM.
-- Emergency lighting kit system can be applied.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 24W | CRI>80 | I01.MLR.16026 . (..) . (...) . (..) . (..) | 2700K | 2555 |
| 3000K | 2620 | |||
| 3500K | 2710 | |||
| 4000K | 2806 | |||
| 5000K | 3002 | |||
| CRI>90 | I01.MLR.16026 . (..) . (...) . (..) . (..) | 2700K | 2324 | |
| 3000K | 2382 | |||
| 3500K | 2466 | |||
| 4000K | 2553 | |||
| 5000K | X | |||
| CRI>98 | I01.MLR.16026 . (..) . (...) . (..) . (..) | 2700K | 1785 | |
| 3000K | 1850 | |||
| 4000K | 1981 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 24 | 24W - 600mA | 827 | CRI>80 - 2700K | 930 | CRI>90 - 3000K |  | FL | 40° - Flood |  | 01 | white |
| 830 | CRI>80 - 3000K | 935 | CRI>90 - 3500K |  | 02 | ral 9010 | |||||
| 835 | CRI>80 - 3500K | 940 | CRI>90 - 4000K |  | 03 | black | |||||
| 840 | CRI>80 - 4000K | 9827 | CRI>98 - 2700K |  | 04 | gray | |||||
| 850 | CRI>80 - 5000K | 9830 | CRI>98 - 3000K |  | 05 | dark gray | |||||
| 927 | CRI>90 - 2700K | 9840 | CRI>98 -4000K |  | 06 | special color |
- Luminaire code
- Strength
- Kelvin
- Reflector angle
- Product color
Frequently Asked Questions
What is the wattage of Pin Spot Maxi?
Pin Spot Maxi has a power of 24W.
What is the protection class of Pin Spot Maxi?
The protection class of Pin Spot Maxi is IP44.
Which certifications and standards does Pin Spot Maxi have?
Pin Spot Maxi carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, Protection class II, IP44.
What is the product code of Pin Spot Maxi?
The product (stock) code of Pin Spot Maxi is I01.MLR.16026.
Where can I download the catalog or PDF of Pin Spot Maxi?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://www.google.com/url?q=https://www.avolux.com/pdf/Pin%2520Spot%2520Maxi%2520MLR.16026.pdf&source=gmail-imap&ust=1793014009000000&usg=AOvVaw0EOWMF4S1kAzWkOUdC_HuT) buttons on this page.
