Silindir Deep 50
Silindir Deep 50 is an AVOLUX LED lighting fixture in the COB Led Recessed Series category with a power of 17W and IP20 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 17W |
| Protection Class | IP20 |
| Shape | built-in |
| Optical | Reflector |
DESCRIPTION
-- Aluminum injection body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- Tempered glass.
-- Classic DALI, 1-10V and Phase DIM options can be applied.
-- High-tech control systems Wireless DIM, Hot DIM and
Dynamic White applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
-- Honeycomb and Color Filter, Viewfinder accessory options can be applied.
-- Narrow, Medium and Wide reflector angle options are available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LEDs.
-- Efficiency up to 88lm/W.
-- High color compatibility: <3 SDCM.
-- Emergency lighting kit system can be applied.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 17W | CRI>80 | I01.MLR.18301 . (..) . (...) . (..) . (..) | 2700K | 1259 |
| 3000K | 1285 | |||
| 3500K | 1287 | |||
| 4000K | 1290 | |||
| 5000K | 1215 | |||
| CRI>90 | I01.MLR.18301 . (..) . (...) . (..) . (..) | 2700K | 1177 | |
| 3000K | 1201 | |||
| 3500K | 1203 | |||
| 4000K | 1206 | |||
| 5000K | X | |||
| CRI>98 | I01.MLR.18301 . (..) . (...) . (..) . (..) | 2700K | 941 | |
| 3000K | 960 | |||
| 4000K | 964 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 17 | 17W - 450mA | 827 | CRI>80 - 2700K | 930 | CRI>90 - 3000K |  | SP | 25° - Spot |  | 01 | white |
| 830 | CRI>80 - 3000K | 935 | CRI>90 - 3500K |  | M.E. | 35° - Medium |  | 02 | ral 9010 | ||
| 835 | CRI>80 - 3500K | 940 | CRI>90 - 4000K |  | FL | 40° - Flood |  | 03 | black | ||
| 840 | CRI>80 - 4000K | 9827 | CRI>98 - 2700K |  | 04 | gray | |||||
| 850 | CRI>80 - 5000K | 9830 | CRI>98 - 3000K |  | 05 | dark gray | |||||
| 927 | CRI>90 - 2700K | 9840 | CRI>98 -4000K |  | 06 | special color |
Luminaire codePowerKelvinReflector angleProduct color
Frequently Asked Questions
What is the wattage of Silindir Deep 50?
Silindir Deep 50 has a power of 17W.
What is the protection class of Silindir Deep 50?
The protection class of Silindir Deep 50 is IP20.
Which certifications and standards does Silindir Deep 50 have?
Silindir Deep 50 carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, Protection class II, IP20.
What is the product code of Silindir Deep 50?
The product (stock) code of Silindir Deep 50 is I01.MLR.18301.
Where can I download the catalog or PDF of Silindir Deep 50?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/downloads/Silindir%20Deep%2050%20I01.MLR.18301.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/Silindir%20Deep%2050%20-%20I01.MLR.18301.rar) buttons on this page.
