Ray
Ray is an AVOLUX LED lighting fixture in the COB Led Tracklight Series category with a power of 31W and IP20 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 31W |
| Protection Class | IP20 |
| Shape | rayspot |
| Optical | Reflector |
DESCRIPTION
-- Aluminum injection body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- With 3-Phase universal rail adapter.
-- Mechanical locking with 90° vertical and 350° horizontal movement capability
joint system.
-- Tempered glass.
-- Classic DALI, 1-10V and Phase DIM options can be applied.
-- High-tech control systems Wireless DIM, Hot DIM and
Dynamic White applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
--Honeycomb Filter, Color Filter, Anti-Glare and Viewfinder accessories
options can be applied.
-- Very Narrow, Narrow, Medium, Wide and Very Wide reflector angle options
available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LED
options are available.
-- Efficiency up to 137lm/W.
-- High color compatibility: <3 SDCM
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 31W | CRI>80 | I01.MLT.18160 . (..) . (...) . (..) . (..) | 2700K | 3888 |
| 3000K | 4045 | |||
| 3500K | 4187 | |||
| 4000K | 4333 | |||
| 5000K | 4636 | |||
| CRI>90 | I01.MLT.18160 . (..) . (...) . (..) . (..) | 2700K | 3499 | |
| 3000K | 3586 | |||
| 3500K | 3712 | |||
| 4000K | 3842 | |||
| 5000K | X | |||
| CRI>98 | I01.MLT.18160 . (..) . (...) . (..) . (..) | 2700K | 2680 | |
| 3000K | 2795 | |||
| 4000K | 2990 | |||
| Meat COB | I01.MLT.18160 . (..) . (...) . (..) . (..) | 1800K | 2238 | |
| Food COB | I01.MLT.18160 . (..) . (...) . (..) . (..) | 2400K | 2304 | |
| Pisces COB | I01.MLT.18160 . (..) . (...) . (..) . (..) | 6600K | 3046 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 31 | 31W - 800mA | 827 | CRI>80 - 2700K | 9827 | CRI>98 - 2700K |  | SP | 20° - Spot |  | 01 | white |
| 28 | 28W - 700mA | 830 | CRI>80 - 3000K | 9830 | CRI>98 - 3000K |  | M.E. | 30° - Medium |  | 02 | ral 9010 |
| 24 | 24W - 600mA | 835 | CRI>80 - 3500K | 9840 | CRI>98 -4000K |  | FL | 40° - Flood |  | 03 | black |
| 20 | 20W - 500mA | 840 | CRI>80 - 4000K | MEAT | 1800K |  | W.F. | 60° - Wide Flood |  | 04 | gray |
| 850 | CRI>80 - 5000K | GOLD | 2400K |  | 05 | dark gray | |||||
| 927 | CRI>90 - 2700K | fish | 6600K |  | 06 | special color | |||||
| 930 | CRI>90 - 3000K | ||||||||||
| 935 | CRI>90 - 3500K | ||||||||||
| 940 | CRI>90 - 4000K |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
Frequently Asked Questions
What is the wattage of Ray?
Ray has a power of 31W.
What is the protection class of Ray?
The protection class of Ray is IP20.
Which certifications and standards does Ray have?
Ray carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, IP20.
What is the product code of Ray?
The product (stock) code of Ray is I01.MLT.18160.
Where can I download the catalog or PDF of Ray?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/067.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/tracklight/RAY%20Tracklight.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/I01.MLT.18160.rar) buttons on this page.
