Orka
Orka is an AVOLUX LED lighting fixture in the COB Led Tracklight Series category with a power of 24W and IP20 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 24W |
| Protection Class | IP20 |
| Shape | rayspot |
| Optical | Lens |
DESCRIPTION
-- Aluminum injection body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- With transformer rail adapter suitable for universal 3-phase rail.
-- Mechanical locking joint system with 90° vertical and 350° horizontal movement capability.
-- Tempered glass.
-- DALI DIM option available.
-- Wireless DIM and Hot DIM applications, which are high-tech control systems, can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010 as well as optional special color options can be applied.
-- Very Narrow, Narrow, Medium, Wide and Very Wide lens angle options are available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LED options are available.
-- Efficiency up to 112lm/W.
-- High color compatibility: <3 SDCM
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 24W | CRI>90 | I01.MLT.60831 . (..) . (...) . (..) . (..) | 2700K | 2058 |
| 3000K | 2100 | |||
| 3500K | 2142 | |||
| 4000K | 2185 | |||
| 5000K | X | |||
| CRI>98 | I01.MLT.60831 . (..) . (...) . (..) . (..) | 2700K | 1545 | |
| 3000K | 1575 | |||
| 3500K | 1610 | |||
| 4000K | 1640 | |||
| 5000K | X |
| 2 | Watts - Driving Current | CRI/Kelvin | CRI/Kelvin | Reflector Angle | 3 | Product Color | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 24 | 24W - 600mA | 927 | CRI>90 - 2700K | 9835 | CRI>98 -3500K |  | SS | 9° - Super Spot |  | 01 | white |
| 21 | 21W - 500mA | 930 | CRI>90 - 3000K | 9840 | CRI>98 -4000K |  | SP | 18° - Spot |  | 02 | ral 9010 |
| 935 | CRI>90 - 3500K |  | M.E. | 24° - Medium |  | 03 | black | ||||
| 940 | CRI>90 - 4000K |  | FL | 36° - Flood |  | 04 | gray | ||||
| 9827 | CRI>98 - 2700K |  | W.F. | 50° - Wide Flood |  | 05 | dark gray | ||||
| 9830 | CRI>98 - 3000K |  | 06 | special color |
Armatür koduGüçKelvinReflektör açısıÜrün renk
Frequently Asked Questions
What is the wattage of Orka?
Orka has a power of 24W.
What is the protection class of Orka?
The protection class of Orka is IP20.
Which certifications and standards does Orka have?
Orka carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, IP20.
What is the product code of Orka?
The product (stock) code of Orka is I01.MLT.60831.
Where can I download the catalog or PDF of Orka?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/downloads/Orka%20I01.MLT.60831.pdf) buttons on this page.
