Quasar Micro
Quasar Micro is an AVOLUX LED lighting fixture in the Pole Mounted Street Fixtures Series category with a power of 25-35W and IP66 protection.
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 25-35W |
| Protection Class | IP66 |
| Shape | Pole Mounted |
| Optical | Lens |
-- LED street lighting fixture.
| Quasar Micro/O07.ST.16320 | |
|---|---|
| System Power | 25W |
| Luminaire Output Lumen CRI>70 - 4000K | 3290lm |
| Driving Current | 350mA |
| Mast Span (a) | 32m |
| Mast Height (h) | 6m |
| Road Width (L) | 3.5m |
| Lighting Class | P3 |
| Optical Type | Maximum pole spacing |
| Quasar Micro/O07.ST.16320 | |
|---|---|
| System Power | 35W |
| Luminaire Output Lumen CRI>70 - 4000K | 4480lm |
| Driving Current | 500mA |
| Mast Span (a) | 32m |
| Mast Height (h) | 6m |
| Road Width (L) | 7m |
| Lighting Class | P2 |
| Optical Type | Maximum pole spacing |
| Armature Data | |
|---|---|
| Product Code | O07.ST.16320.35.740.05 |
| Family Name | QuasarMicro |
| Material | Aluminum Injection |
| LED Life | L70/B50 50000h |
| Optical | Asymmetric Street Lighting Lens |
| Luminaire Maximum Power | 35W |
| Number of LEDs | 24 |
| Circuit | 24S2P |
| LED Type | 3535 |
| CRI | 70 |
| Operating Temperature | -20°C / +50°C |
| Protection | IP66 |
1- Product code / Armature code
2- Power
3- CRI / Kelvin
4- Color / Product color
Frequently Asked Questions
What is the wattage of Quasar Micro?
Quasar Micro has a power of 25-35W.
What is the protection class of Quasar Micro?
The protection class of Quasar Micro is IP66.
Which certifications and standards does Quasar Micro have?
Quasar Micro carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, Protection class II, IP66, IK09.
What is the product code of Quasar Micro?
The product (stock) code of Quasar Micro is O07.ST.16320.
Where can I download the catalog or PDF of Quasar Micro?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/034-035.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/Dire%C4%9Fe%20Monte/Quasar.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/outdoor/4.%20Quasar%20Micro.zip) buttons on this page.
