Purelite
Purelite is an AVOLUX LED lighting fixture in the COB Led Tracklight Series category with a power of 42W and IP20 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 42W |
| Protection Class | IP20 |
| Shape | rayspot |
| Optical | Reflector |
DESCRIPTION
-- Aluminum injection body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- With 3-Phase universal rail adapter.
-- Mechanical with 180° vertical and 350° horizontal movement capability
locking joint system.
-- Classic DALI, 1-10V and Phase DIM options can be applied.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
-- Anti-glare blinds and Color Filter accessories can be applied.
-- Medium and Wide angle half asymmetric reflector options are available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LED
options are available.
-- Efficiency up to 127lm/W.
-- High color compatibility: <3 SDCM
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 42W | CRI>80 | I01.MLT.40237 . (..) . (...) . (..) . (..) | 2700K | 4872 |
| 3000K | 4993 | |||
| 3500K | 5168 | |||
| 4000K | 5349 | |||
| 5000K | 5670 | |||
| CRI>90 | I01.MLT.40237 . (..) . (...) . (..) . (..) | 2700K | 4384 | |
| 3000K | 4493 | |||
| 3500K | 4651 | |||
| 4000K | 4814 | |||
| 5000K | X | |||
| CRI>98 | I01.MLT.40237 . (..) . (...) . (..) . (..) | 2700K | 3368 | |
| 3000K | 3491 | |||
| 4000K | 3668 | |||
| Meat COB | I01.MLT.40237 . (..) . (...) . (..) . (..) | 1800K | 2585 | |
| Food COB | I01.MLT.40237 . (..) . (...) . (..) . (..) | 2400K | 2865 | |
| Pisces COB | I01.MLT.40237 . (..) . (...) . (..) . (..) | 6600K | 3781 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 42 | 42W - 1050mA | 827 | CRI>80 - 2700K | 9827 | CRI>98 - 2700K |  | HM | 1x25° - Half Batwing |  | 01 | white |
| 35 | 35W - 900mA | 830 | CRI>80 - 3000K | 9830 | CRI>98 - 3000K |  | H.F. | 1x45° - Half Batwing |  | 02 | ral 9010 |
| 31 | 31W - 800mA | 835 | CRI>80 - 3500K | 9840 | CRI>98 -4000K |  | 03 | black | |||
| 28 | 28W - 700mA | 840 | CRI>80 - 4000K | MEAT | 1800K |  | 04 | gray | |||
| 850 | CRI>80 - 5000K | GOLD | 2400K |  | 05 | dark gray | |||||
| 927 | CRI>90 - 2700K | fish | 6600K |  | 06 | special color | |||||
| 930 | CRI>90 - 3000K | ||||||||||
| 935 | CRI>90 - 3500K | ||||||||||
| 940 | CRI>90 - 4000K |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
Frequently Asked Questions
What is the wattage of Purelite?
Purelite has a power of 42W.
What is the protection class of Purelite?
The protection class of Purelite is IP20.
Which certifications and standards does Purelite have?
Purelite carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, IP20.
What is the product code of Purelite?
The product (stock) code of Purelite is I01.MLT.40237.
Where can I download the catalog or PDF of Purelite?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/136.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/tracklight/PURELITE%20Tracklight.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/PureliteI01.MLT.40237.rar) buttons on this page.
