Castillo
Castillo is an AVOLUX LED lighting fixture in the Bollard Series category with a power of 15W and IP66 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 15W |
| Protection Class | IP66 |
| Shape | bollard |
| Optical | Lens |
DESCRIPTION
-- Corrosion resistant alu. body
--Tempered glass
-- Galvanized steel flange
-- IK08 mechanically protected
-- IP66 Protection Class
-- Chromated surface pre-cleaning
-- Electrostatic powder coated
-- All fasteners are stainless
-- Electrical connection Class I
-- CCT : 2700K - 4000K - 6500K
-- 220-240V 50-60Hz energy input
-- Control System: On/Off - DALI
-- Color Rendering: >80
-- L70 Life: >72,000 Hours Ta=45°C
-- Operating Ambient Temperature: --20°C/+45°C
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 15W | CRI>80 | O07.BL.07701 . (..) . (...) . (..) . (..) | 2700K | 1070 |
| 3000K | 1092 | |||
| 3500K | 1114 | |||
| 4000K | 1136 | |||
| 5000K | 1159 | |||
| 6500K | X |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 5 | Product Color | |
|---|---|---|---|---|---|---|---|---|
| 15 | 15W | 827 | CRI>80 - 2700K |  | 01 | white | ||
| 830 | CRI>80 - 3000K |  | 02 | ral 9010 | ||||
| 835 | CRI>80 - 3500K |  | 03 | black | ||||
| 840 | CRI>80 - 4000K |  | 04 | gray | ||||
| 850 | CRI>80 - 5000K |  | 05 | dark gray | ||||
 | 06 | special color |
1- Product code / Armature code2- Power / Power3- CRI / Kelvin
4- Reflector angle
Frequently Asked Questions
What is the wattage of Castillo?
Castillo has a power of 15W.
What is the protection class of Castillo?
The protection class of Castillo is IP66.
Which certifications and standards does Castillo have?
Castillo carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IP66, IK08.
What is the product code of Castillo?
The product (stock) code of Castillo is O07.BL.07701.
Where can I download the catalog or PDF of Castillo?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/downloads/outdoor/Castillo%20O07.BL.07701.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/outdoor/Castillo.pdf) buttons on this page.
