Pico 48V
Pico 48V is an AVOLUX LED lighting fixture in the 48V Series category with a power of 2x5W and IP20 protection.
Product icons
| Input Voltage | 48V DC |
|---|---|
| Wattage | 2x5W |
| Protection Class | IP20 |
| Shape | rayspot |
| Optical | Reflector |
DESCRIPTION
-- Aluminum injection body.
-- With 48V DC input.
-- Intelligent cooling design with passive cooling technology.
-- With DC/DC transformer adapter suitable for Stucchi 48V rail system.
-- It has the ability to move 90° vertically and 350° horizontally.
-- Tempered glass.
-- Classic 1-10V and DALI DIM options can be applied.
-- Wireless DIM and Hot DIM, which are high-tech control systems
applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
--Honeycomb Filter, Color Filter, Anti-Glare and Viewfinder accessories
options can be applied.
-- Medium, Wide and Very Wide reflector angle options are available.
-- Efficiency up to 71lm/W.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 2x5W | CRI>90 | I01.MLT.15162 . (..) . (...) . (..) . (..) | 2700K | 850 |
| 3000K | 872 | |||
| 3500K | 888 | |||
| 4000K | 928 | |||
| 5000K | X | |||
| CRI>98 | I01.MLT.15162 . (..) . (...) . (..) . (..) | 2700K | 654 | |
| 3000K | 662 | |||
| 4000K | 704 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 5 | 2x5W - 100mA | 927 | CRI>90 - 2700K | 9827 | CRI>98 - 2700K |  | M.E. | 2x30° - Medium |  | 01 | white |
| 930 | CRI>90 - 3000K | 9830 | CRI>98 - 3000K |  | FL | 2x40° - Flood |  | 02 | ral 9010 | ||
| 935 | CRI>90 - 3500K | 9840 | CRI>98 - 4000K |  | W.F. | 2x60° - Wide Flood |  | 03 | black | ||
| 940 | CRI>90 - 4000K |  | 04 | gray | |||||||
 | 05 | dark gray | |||||||||
 | 06 | special color |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
Frequently Asked Questions
What is the wattage of Pico 48V?
Pico 48V has a power of 2x5W.
What is the protection class of Pico 48V?
The protection class of Pico 48V is IP20.
Which certifications and standards does Pico 48V have?
Pico 48V carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class III, IP20.
What is the product code of Pico 48V?
The product (stock) code of Pico 48V is I01.MLT.15162.
Where can I download the catalog or PDF of Pico 48V?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/218-219.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/48V/PICO%2048V%20Tracklight.pdf) buttons on this page.
