Lightray
Lightray is an AVOLUX LED lighting fixture in the Facade Lighting Series category with a power of 12-23W and IP66 protection.
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 12-23W |
| Protection Class | IP66 |
| Shape | surface mounted |
| Optical | Lens |
-- LED facade lighting fixture with symmetrical light output.
| Length (A) | Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|---|
| 520mm | 12W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | 2700K | 980 |
| 3000K | 995 | ||||
| 3500K | 1046 | ||||
| 4000K | 1060 | ||||
| 5000K | 1068 | ||||
| 6500K | 1079 | ||||
| 7.8W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | Red | 647 | |
| 11W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | Green | 1224 | |
| 11.2W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | Blue | 628 | |
| 11.5W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | Amber | 1231 | |
| 10W | Dynamic White | O07.WL.16035 . (..) . (...) . (..) . (..) | 2700K - 6000K | 625 - 791 | |
| 10W | RGBW | O07.WL.16035 . (..) . (...) . (..) . (..) | RGBW | 522 | |
| 1000mm | 24W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | 2700K | 1960 |
| 3000K | 1990 | ||||
| 3500K | 2092 | ||||
| 4000K | 2121 | ||||
| 5000K | 2136 | ||||
| 6500K | 2159 | ||||
| 15.6W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | Red | 1294 | |
| 22W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | Green | 2448 | |
| 22.2W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | Blue | 1256 | |
| 23W | CRI>80 | O07.WL.16035 . (..) . (...) . (..) . (..) | Amber | 2462 | |
| 20W | Dynamic White | O07.WL.16035 . (..) . (...) . (..) . (..) | 2700K - 6000K | 1250 - 1582 | |
| 20W | RGBW | O07.WL.16035 . (..) . (...) . (..) . (..) | RGBW | 1044 |
| Length (A) | Watts - Driving Current | CRI/Kelvin | CRI/Kelvin | CRI/Kelvin | Light Angle | 5 | Product Color | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1000mm | 23W | 24W - 150mA | 827 | CRI>80 - 2700K | 625 | Red |  | SS | 17° - Super Spot |  | 01 | white |
| 520mm | 12W | 12W - 150mA | 830 | CRI>80 - 3000K | 525 | Green |  | SP | 25° - Spot |  | 02 | ral 9010 |
| 835 | CRI>80 - 3500K | 470 | Blue |  | M.E. | 35° - Medium |  | 03 | black | |||
| 840 | CRI>80 - 4000K | 590 | Amber |  | FL | 46° - Flood |  | 04 | gray | |||
| 850 | CRI>80 - 5000K | T.W. | 2700K - 6000K |  | OV | 25° x 46° - Oval |  | 05 | dark gray | |||
| 865 | CRI>80 - 6500K | RGBW | RGBW |  | 06 | special color | ||||||
1- Product code / Armature code
2- Power
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Lightray?
Lightray has a power of 12-23W.
What is the protection class of Lightray?
The protection class of Lightray is IP66.
Which certifications and standards does Lightray have?
Lightray carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IP66, IK07.
What is the product code of Lightray?
The product (stock) code of Lightray is O07.WL.16035.
Where can I download the catalog or PDF of Lightray?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/476-477.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/D%C4%B1%C5%9F%20Cephe/Lightray.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/outdoor/O07.WL.16035.rar) buttons on this page.
