Lazer Maxi
Lazer Maxi is an AVOLUX LED lighting fixture in the Facade Lighting Series category with a power of 8W and IP66 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 8W |
| Protection Class | IP66 |
| Shape | surface mounted |
| Optical | Lens |
DESCRIPTION
-- LED facade lighting fixture with symmetrical light output.
-- Corrosion resistant aluminum profile body and aluminum injection
end cap.
-- Thanks to the bracketed mounting system, it can be mounted on floor, wall and ceiling surfaces.
It can be easily installed.
-- 220-240V / 50-60Hz energy input.
-- Very narrow, narrow, medium, wide and oval angle options are available.
-- 2700K, 3000K, 3500K, 4000K, 5000K and 6500K color temperature
options are available.
-- Green, red, blue and amber color options are available.
-- Optionally, jumper between luminaires with 2 cable entry terminals
can be done.
-- IP protection is provided without any problems with silicone gaskets.
-- All external screws are stainless.
-- Corrosion and salt resistant thanks to double-layer polyester powder paint.
-- Efficiency up to 114lm/W.
-- High color compatibility: <3 SDCM
-- RGB and RGBW options are available.
-- Stainless cable gland is used in the luminaire and 220V main
The mains cable has an IP68 protected connector.
-- Mechanical locking system.
-- Thanks to flexible mounting legs, 180° movement is provided in a single plane.
-- Safe system with L80 B10 50000 hour life parameters.
-- Five-year warranty.
| Length (A) | Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|---|
| 215mm | 8W | CRI>80 | O07.WL.16125 . (..) . (...) . (..) . (..) | 2700K | 470 |
| 3000K | 495 | ||||
| 3500K | 520 | ||||
| 4000K | 535 | ||||
| 5000K | 554 | ||||
| 6500K | 565 | ||||
| 5W | CRI>80 | O07.WL.16125 . (..) . (...) . (..) . (..) | Red | 210 | |
| 7W | CRI>80 | O07.WL.16125 . (..) . (...) . (..) . (..) | Green | 375 | |
| 7W | CRI>80 | O07.WL.16125 . (..) . (...) . (..) . (..) | Blue | 170 | |
| 7W | CRI>80 | O07.WL.16125 . (..) . (...) . (..) . (..) | Amber | 420 |
| Length (A) | Watts - Driving Current | CRI/Kelvin | CRI/Kelvin | CRI/Kelvin | Light Angle | 5 | Product Color | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 215mm | 8W | 8W - 350mA | 827 | CRI>80 - 2700K | 625 | Red |  | SS | 4° - Super Spot |  | 01 | white |
| 830 | CRI>80 - 3000K | 525 | Green |  | 02 | ral 9010 | ||||||
| 835 | CRI>80 - 3500K | 470 | Blue |  | 03 | black | ||||||
| 840 | CRI>80 - 4000K | 590 | Amber |  | 04 | gray | ||||||
| 850 | CRI>80 - 5000K |  | 05 | dark gray | ||||||||
| 865 | CRI>80 - 6500K |  | 06 | special color | ||||||||
1- Product code / Armature code
2- Power / Güç
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Lazer Maxi?
Lazer Maxi has a power of 8W.
What is the protection class of Lazer Maxi?
The protection class of Lazer Maxi is IP66.
Which certifications and standards does Lazer Maxi have?
Lazer Maxi carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IP66, IK08.
What is the product code of Lazer Maxi?
The product (stock) code of Lazer Maxi is O07.WL.16125.
Where can I download the catalog or PDF of Lazer Maxi?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/469.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/D%C4%B1%C5%9F%20Cephe/Magiclight.pdf) buttons on this page.
