Darkline Suspendant
Darkline Suspendant is an AVOLUX LED lighting fixture in the Linear Profile Led Series category with a power of 14-49W and IP20 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 14-49W |
| Protection Class | IP20 |
| Shape | Linear |
| Optical | Reflector |
| width, height | 68-90mm |
| Mounting Type | Stalactite |
DESCRIPTION
| Armature Data | |
|---|---|
| Product Code | I02.LL.19290.1144.034.830.01 |
| Family Name | Darkline |
| Material | Aluminum |
| Format | linear |
| Profile Width | 68mm |
| Profile Height | 90mm |
| Installation Type | Stalactite |
| Productivity | >46lm/W |
| CRI | 80 |
| Light Distribution | Symmetrical Wide Open |
| Protection Class | 20 |
| Luminaire Life | L70/B50 50000h |
| Optical | Honeycomb Filter |
| UGR | <16 |
| Length (A) | CRI | Order Code | Kelvin | 14W 250mA lm | 18W 350mA lm |
|---|---|---|---|---|---|
| 584mm | CRI>80 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 553 | 694 |
| 3000K | 571 | 717 | |||
| 3500K | 579 | 728 | |||
| 4000K | 602 | 756 | |||
| 5000K | 610 | 767 | |||
| CRI>90 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 464 | 583 | |
| 3000K | 478 | 600 | |||
| 3500K | 486 | 611 | |||
| 4000K | 504 | 633 |
| Length (A) | CRI | Order Code | Kelvin | 19W 250mA lm | 26W 350mA lm |
|---|---|---|---|---|---|
| 864mm | CRI>80 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 785 | 1051 |
| 3000K | 811 | 1085 | |||
| 3500K | 823 | 1102 | |||
| 4000K | 855 | 1144 | |||
| 5000K | 867 | 1160 | |||
| CRI>90 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 660 | 883 | |
| 3000K | 679 | 908 | |||
| 3500K | 691 | 925 | |||
| 4000K | 716 | 959 |
| Length (A) | CRI | Order Code | Kelvin | 24W 250mA lm | 34W 350mA lm |
|---|---|---|---|---|---|
| 1144mm | CRI>80 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 1036 | 1437 |
| 3000K | 1070 | 1483 | |||
| 3500K | 1086 | 1506 | |||
| 4000K | 1128 | 1564 | |||
| 5000K | 1144 | 1587 | |||
| CRI>90 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 870 | 1207 | |
| 3000K | 895 | 1242 | |||
| 3500K | 912 | 1265 | |||
| 4000K | 945 | 1311 |
| Length (A) | CRI | Order Code | Kelvin | 30W 250mA lm | 42W 350mA lm |
|---|---|---|---|---|---|
| 1424mm | CRI>80 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 1351 | 1853 |
| 3000K | 1394 | 1912 | |||
| 3500K | 1416 | 1942 | |||
| 4000K | 1470 | 2016 | |||
| 5000K | 1491 | 2045 | |||
| CRI>80 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 1134 | 1556 | |
| 3000K | 1167 | 1601 | |||
| 3500K | 1189 | 1630 | |||
| 4000K | 1232 | 1690 |
| Length (A) | CRI | Order Code | Kelvin | 36W 250mA lm | 49W 350mA lm |
|---|---|---|---|---|---|
| 1704mm | CRI>80 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 1687 | 2252 |
| 3000K | 1741 | 2324 | |||
| 3500K | 1768 | 2360 | |||
| 4000K | 1836 | 2450 | |||
| 5000K | 1863 | 2486 | |||
| CRI>90 | I02.LL.19290 . (...) . (...) . (...) . (...) | 2700K | 1417 | 1891 | |
| 3000K | 1458 | 1945 | |||
| 3500K | 1485 | 1981 | |||
| 4000K | 1539 | 2053 |
| 2 | Length (A) | 3 | Watts - Driving Current | 4 | CRI/Kelvin | 4 | CRI/Kelvin | 5 | Product Color | |
|---|---|---|---|---|---|---|---|---|---|---|
| 584mm | 14W | 14W (Direct) - 250mA | 827 | CRI>80 - 2700K | 927 | CRI>90 - 2700K |  | 01 | white | |
| 18W | 18W (Direct) - 350mA | |||||||||
| 864mm | 19W | 19W (Direct) - 250mA | 830 | CRI>80 - 3000K | 930 | CRI>90 - 3000K |  | 02 | ral 9010 | |
| 26W | 26W (Direct) - 350mA | |||||||||
| 1144mm | 24W | 24W (Direct) - 250mA | 835 | CRI>80 - 3500K | 935 | CRI>90 - 3500K |  | 03 | black | |
| 34W | 34W (Direct) - 350mA | |||||||||
| 1424mm | 30W | 30W (Direct) - 250mA | 840 | CRI>80 - 4000K | 940 | CRI>90 - 4000K |  | 04 | gray | |
| 42W | 42W (Direct) - 350mA | |||||||||
| 1704mm | 36W | 36W (Direct) - 250mA | 850 | CRI>80 - 5000K |  | 05 | dark gray | |||
| 49W | 49W (Direct) - 350mA | |||||||||
 | 06 | special color |
Frequently Asked Questions
What is the wattage of Darkline Suspendant?
Darkline Suspendant has a power of 14-49W.
What is the protection class of Darkline Suspendant?
The protection class of Darkline Suspendant is IP20.
Which certifications and standards does Darkline Suspendant have?
Darkline Suspendant carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, IP20.
What is the product code of Darkline Suspendant?
The product (stock) code of Darkline Suspendant is I02.LL.19290.
Where can I download the catalog or PDF of Darkline Suspendant?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/linealed/222-223.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/linealedpanel/DARKLINE%20Linea%20Led.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/linea/I02.LL.19290.rar) buttons on this page.
