Cub Mini Pendant
Cub Mini Pendant is an AVOLUX LED lighting fixture in the COB Led Pendant Series category with a power of 7W and IP44 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 7W |
| Protection Class | IP44 |
| Shape | Stalactite |
| Optical | Reflector |
DESCRIPTION
-- Aluminum body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- Tempered glass.
-- Classic DALI, 1-10V and Phase DIM options can be applied.
-- Wireless DIM, Hot DIM and Dynamic White applications, which are high-tech control systems, can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010 as well as optional special color options can be applied.
--Honeycomb Filter and Color Filter accessory options are applicable.
-- Narrow and Wide reflector angle options are available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LED options are available.
-- Efficiency up to 117lm/W.
-- High color compatibility: <3 SDCM.
-- Steel pendant wire up to 5.00m height option.
-- The luminaire is supplied with a rosette at the connection point to the ceiling.
-- Emergency lighting kit system can be applied if the profile length is extended.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 7W | CRI>80 | I01.MLP.14024 . (..) . (...) . (..) . (..) | 2700K | 720 |
| 3000K | 737 | |||
| 3500K | 763 | |||
| 4000K | 790 | |||
| 5000K | 845 | |||
| CRI>90 | I01.MLP.14024 . (..) . (...) . (..) . (..) | 2700K | 648 | |
| 3000K | 663 | |||
| 3500K | 686 | |||
| 4000K | 710 | |||
| 5000K | X | |||
| CRI>98 | I01.MLP.14024 . (..) . (...) . (..) . (..) | 2700K | 496 | |
| 3000K | 516 | |||
| 4000K | 540 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 7 | 7W - 180mA | 827 | CRI>80 - 2700K | 930 | CRI>90 - 3000K |  | SP | 20° - Spot |  | 01 | white |
| 4 | 4W - 100mA | 830 | CRI>80 - 3000K | 935 | CRI>90 - 3500K |  | M.E. | 35° - Medium |  | 02 | ral 9010 |
| 835 | CRI>80 - 3500K | 940 | CRI>90 - 4000K |  | FL | 45° - Flood |  | 03 | black | ||
| 840 | CRI>80 - 4000K | 9827 | CRI>98 - 2700K |  | 04 | gray | |||||
| 850 | CRI>80 - 5000K | 9830 | CRI>98 - 3000K |  | 05 | dark gray | |||||
| 927 | CRI>90 - 2700K | 9840 | CRI>98 -4000K |  | 06 | special color |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
Frequently Asked Questions
What is the wattage of Cub Mini Pendant?
Cub Mini Pendant has a power of 7W.
What is the protection class of Cub Mini Pendant?
The protection class of Cub Mini Pendant is IP44.
Which certifications and standards does Cub Mini Pendant have?
Cub Mini Pendant carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, IP44.
What is the product code of Cub Mini Pendant?
The product (stock) code of Cub Mini Pendant is I01.MLP.14024.
Where can I download the catalog or PDF of Cub Mini Pendant?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/656.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/pendant/CUB%20Pendant.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/Cub%20Mini%20Pendant%20I01.MLP.14024.rar) buttons on this page.
