City Mini
City Mini is an AVOLUX LED lighting fixture in the Pole Mounted Street Fixtures Series category with a power of 60W and IP66 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 60W |
| Protection Class | IP66 |
| Shape | Pole Mounted |
| Optical | Lens |
DESCRIPTION
-- LED street lighting fixture.
-- Corrosion resistant aluminum injection body.
-- With silicone gasket.
-- All external metal parts are made of stainless steel.
-- UV resistant polycarbonate lens optic
-- 10KV power surge protector can be integrated.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design.
-- High lighting comfort.
-- Color tolerance max. 3SDCM.
-- Suitable for use on poles with a maximum height of 10 meters.
-- Compatible with console inner diameter Ø45 - Ø60mm.
-- Efficient structure reaching up to 135lm/W.
-- Astro dim option is available.
-- Alternatively a motion sensor can be integrated.
-- Besides the standard 4000K light color, alternatively 2700K, 3000K,
3500K, 5000K and 6500K options are also available.
| City Maxi / O07.ST.15410 | |
|---|---|
| System Power | 60W |
| Luminaire Output Lumen CRI>70 - 4000K | 6737lm |
| Driving Current | 450mA |
| Mast Span (a) | 37m |
| Mast Height (h) | 8m |
| Road Width (L) | 7m |
| Lighting Class | P2 |
| Optical Type | Maximum pole spacing |
| Armature Data | |
|---|---|
| Product Code | O07.ST.15410.60.840.05 |
| Family Name | CityMini |
| Material | Aluminum Injection |
| LED Life | L70/B50 50000h |
| Optical | Asymmetric Street Lighting Lens |
| Luminaire Maximum Power | 60W |
| Number of LEDs | 120 |
| Circuit | 24S2P |
| LED Type | 3535 |
| CRI | 80 |
| Operating Temperature | -20°C / +50°C |
| Protection | IP66 |
1- Product code / Armature code2- Power / Power3- CRI / Kelvin4- Color / Product color
Frequently Asked Questions
What is the wattage of City Mini?
City Mini has a power of 60W.
What is the protection class of City Mini?
The protection class of City Mini is IP66.
Which certifications and standards does City Mini have?
City Mini carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, Protection class II, IP66, IK08.
What is the product code of City Mini?
The product (stock) code of City Mini is O07.ST.15410.
Where can I download the catalog or PDF of City Mini?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/150-151.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/Dire%C4%9Fe%20Monte/City.pdf) buttons on this page.
