Asya Short Arm
Asya Short Arm is an AVOLUX LED lighting fixture in the 48V Series category with a power of 2W and IP20 protection.
Product icons
| Input Voltage | 48V DC |
|---|---|
| Wattage | 2W |
| Protection Class | IP20 |
| Shape | rayspot |
| Optical | Lens |
DESCRIPTION
-- Aluminum injection body.
-- With 48V DC input.
-- Intelligent cooling design with passive cooling technology.
-- With DC/DC transformer adapter suitable for Stucchi 48V rail system
-- It has the ability to move 90° vertically and 350° horizontally.
-- Classic 1-10V and DALI DIM options can be applied.
-- Wireless DIM application with high-tech control system
can be done.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
-- Medium, Wide and Very Wide square frame lens angle options are available.
-- Efficiency up to 119lm/W.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 2W | CRI>90 | I01.MLT.99901 . (..) . (...) . (..) . (..) | 2700K | 224 |
| 3000K | 230 | |||
| 3500K | 234 | |||
| 4000K | 237 | |||
| 5000K | X | |||
| CRI>98 | I01.MLT.99901 . (..) . (...) . (..) . (..) | 2700K | 172 | |
| 3000K | 175 | |||
| 4000K | 179 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 2 | 2W - 500mA | 927 | CRI>90 - 2700K | 9827 | CRI>98 - 2700K |  | M.E. | 28° - Medium |  | 01 | white |
| 930 | CRI>90 - 3000K | 9830 | CRI>98 - 3000K |  | FL | 48° - Flood |  | 02 | ral 9010 | ||
| 935 | CRI>90 - 3500K | 9840 | CRI>98 - 4000K |  | W.F. | 26x36° - Wide Flood |  | 03 | black | ||
| 940 | CRI>90 - 4000K |  | 04 | gray | |||||||
 | 05 | dark gray | |||||||||
 | 06 | special color |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
Frequently Asked Questions
What is the wattage of Asya Short Arm?
Asya Short Arm has a power of 2W.
What is the protection class of Asya Short Arm?
The protection class of Asya Short Arm is IP20.
Which certifications and standards does Asya Short Arm have?
Asya Short Arm carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class III, IP20.
What is the product code of Asya Short Arm?
The product (stock) code of Asya Short Arm is I01.MLT.99901.
Where can I download the catalog or PDF of Asya Short Arm?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/194-195.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/48V/ASYA%2048V%20Tracklight.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/Asya%20Short%20ArmI01.MLT.99901.rar) buttons on this page.
