Terra Mini
Terra Mini is an AVOLUX LED lighting fixture in the Recessed Series category with a power of 20-28W and IP66 protection.
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 20-28W |
| Protection Class | IP66 |
| Shape | built-in |
| Optical | Reflector |
| Diameter | Ø160mm |
-- Aluminum injection body.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 28W | CRI>80 | O07.MLR.10204 . (..) . (...) . (..) . (..) | 2700K | 3041 |
| 3000K | 3176 | |||
| 3500K | 3248 | |||
| 4000K | 3325 | |||
| 5000K | 3345 | |||
| 6500K | X |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 28 | 28W - 700mA | 827 | CRI>80 - 2700K |  | SP | 20° - Spot |  | 01 | white | ||
| 24 | 24W - 600mA | 830 | CRI>80 - 3000K |  | M.E. | 30° - Medium |  | 02 | ral 9010 | ||
| 20 | 20W - 500mA | 835 | CRI>80 - 3500K |  | FL | 40° - Flood |  | 03 | black | ||
| 840 | CRI>80 - 4000K |  | W.F. | 60° - Wide Flood |  | 04 | gray | ||||
| 850 | CRI>80 - 5000K |  | 05 | dark gray | |||||||
 | 06 | special color |
1- Product code / Armature code
Frequently Asked Questions
What is the wattage of Terra Mini?
Terra Mini has a power of 20-28W.
What is the protection class of Terra Mini?
The protection class of Terra Mini is IP66.
Which certifications and standards does Terra Mini have?
Terra Mini carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class II, IP66, IK08.
What is the product code of Terra Mini?
The product (stock) code of Terra Mini is O07.MLR.10204.
Where can I download the catalog or PDF of Terra Mini?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/639.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/Ankastre/Terra.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/outdoor/TERRA%20M%C4%B0N%C4%B0%20-%20O07.MLR.10204.zip) buttons on this page.
