Space Mini
Space Mini is an AVOLUX LED lighting fixture in the Power LED Recessed Series category with a power of 14W and IP20 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 14W |
| Protection Class | IP20 |
| Shape | built-in |
| Optical | Reflector |
DESCRIPTION
-- Aluminum injection body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- Mechanical locking joint system with 60° vertical movement capability.
-- Classic DALI DIM option can be applied.
-- Wireless DIM application with high-tech control system
can be done.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
--Honeycomb Filter and Color Filter accessory options are applicable.
-- Very Narrow, Medium and Very Wide reflector angle options are available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LED
options are available.
-- Efficiency up to 98lm/W.
-- High color compatibility: <3 SDCM.
-- Emergency lighting kit system can be applied.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 14W | CRI>80 | I01.MLR.40250 . (..) . (...) . (..) . (..) | 2700K | 1054 |
| 3000K | 1087 | |||
| 3500K | 1109 | |||
| 4000K | 1132 | |||
| 5000K | 1166 | |||
| CRI>90 | I01.MLR.40250 . (..) . (...) . (..) . (..) | 2700K | 937 | |
| 3000K | 966 | |||
| 3500K | 986 | |||
| 4000K | 1006 | |||
| 5000K | X |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 14 | 14W - 500mA | 827 | CRI>80 - 2700K | 927 | CRI>90 - 2700K |  | SS | 15° - Super Spot |  | 01 | white |
| 10 | 10W - 350mA | 830 | CRI>80 - 3000K | 930 | CRI>90 - 3000K |  | M.E. | 34° - Medium |  | 02 | ral 9010 |
| 6 | 6W - 200mA | 835 | CRI>80 - 3500K | 935 | CRI>90 - 3500K |  | W.F. | 50° - Wide Flood |  | 03 | black |
| 840 | CRI>80 - 4000K | 940 | CRI>90 - 4000K |  | 04 | gray | |||||
| 850 | CRI>80 - 5000K |  | 05 | dark gray | |||||||
 | 06 | special color |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
Frequently Asked Questions
What is the wattage of Space Mini?
Space Mini has a power of 14W.
What is the protection class of Space Mini?
The protection class of Space Mini is IP20.
Which certifications and standards does Space Mini have?
Space Mini carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, Protection class II, IP20.
What is the product code of Space Mini?
The product (stock) code of Space Mini is I01.MLR.40250.
Where can I download the catalog or PDF of Space Mini?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/746-747.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/downlight/SPACE%20Recessed.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/Space%20Mini%20-%20I01.MLR.40250.rar) buttons on this page.
