Silindir Deep 60
Silindir Deep 60 is an AVOLUX LED lighting fixture in the COB Led Surface Mounted Series category with a power of 15W and IP44 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 15W |
| Protection Class | IP44 |
| Shape | surface mounted |
| Optical | Reflector |
DESCRIPTION
-- Aluminum injection body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- Tempered glass.
-- Classic DALI, 1-10V and Phase DIM options can be applied.
-- Wireless DIM and Hot DIM, which are high-tech control systems
applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
-- Narrow, Medium and Wide reflector angle options are available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LED
options are available.
-- Efficiency up to 92lm/W.
-- High color compatibility: <3 SDCM.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 15W | CRI>80 | I01.MLS.18300 . (..) . (...) . (..) . (..) | 2700K | 1342 |
| 3000K | 1369 | |||
| 3500K | 1372 | |||
| 4000K | 1376 | |||
| 5000K | 1403 | |||
| CRI>90 | I01.MLS.18300 . (..) . (...) . (..) . (..) | 2700K | 1255 | |
| 3000K | 1280 | |||
| 3500K | 1283 | |||
| 4000K | 1286 | |||
| 5000K | X | |||
| CRI>98 | I01.MLS.18300 . (..) . (...) . (..) . (..) | 2700K | 1004 | |
| 3000K | 1024 | |||
| 4000K | 1026 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 15 | 15W - 350mA | 827 | CRI>80 - 2700K | 930 | CRI>90 - 3000K |  | SP | 20° - Spot |  | 01 | white |
| 830 | CRI>80 - 3000K | 935 | CRI>90 - 3500K |  | M.E. | 30° - Medium |  | 02 | ral 9010 | ||
| 835 | CRI>80 - 3500K | 940 | CRI>90 - 4000K |  | FL | 40° - Flood |  | 03 | black | ||
| 840 | CRI>80 - 4000K | 9827 | CRI>98 - 2700K |  | 04 | gray | |||||
| 850 | CRI>80 - 5000K | 9830 | CRI>98 - 3000K |  | 05 | dark gray | |||||
| 927 | CRI>90 - 2700K | 9840 | CRI>98 -4000K |  | 06 | special color |
Luminaire codePowerKelvinReflector angleProduct color
Frequently Asked Questions
What is the wattage of Silindir Deep 60?
Silindir Deep 60 has a power of 15W.
What is the protection class of Silindir Deep 60?
The protection class of Silindir Deep 60 is IP44.
Which certifications and standards does Silindir Deep 60 have?
Silindir Deep 60 carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, IP44.
What is the product code of Silindir Deep 60?
The product (stock) code of Silindir Deep 60 is I01.MLS.18300.
Where can I download the catalog or PDF of Silindir Deep 60?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/downloads/Silindir%20Deep%2060%20I01.MLS.18300.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/Silindir%20Deep%2060%20-%20I01.MLS.18300.rar) buttons on this page.
