Kartal ST
Kartal ST is an AVOLUX LED lighting fixture in the Pole Mounted Street Fixtures Series category with a power of 104-152W and IP66 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 104-152W |
| Protection Class | IP66 |
| Shape | Pole Mounted |
| Optical | Lens |
DESCRIPTION
-- LED street lighting fixture.
-- With silicone gasket.
-- All external metal parts are made of stainless steel.
-- Tempered glass.
-- 10KV power surge protector can be integrated.
-- 220-240V / 50-60Hz energy input.
-- Suitable for use up to 6m pole height.
-- Efficient optical structure in compliance with street lighting standards.
-- Transformer unit that does not require equipment can be intervened.
-- Compatible with console inner diameter Ø42 - Ø63mm.
-- Efficient structure reaching up to 141lm/W.
-- Compatible with 500mA and 700mA driving currents.
-- 1-10V, DALI and Astro dim options are available.
-- Alternatively a motion sensor can be integrated.
-- Besides the standard 4000K light color, alternatively 2700K, 3000K,
3500K, 5000K and 6500K options are also available.
| Eagle ST/O07.ST.16955 | |
|---|---|
| System Power | 104W |
| Luminaire Output Lumen CRI>70 - 4000K | 14668lm |
| Driving Current | 500mA |
| Mast Span (a) | 20m |
| Mast Height (h) | 5m |
| Road Width (L) | 14m |
| Lighting Class | - |
| Optical Type | Maximum pole spacing |
| Eagle ST/O07.ST.16955 | |
|---|---|
| System Power | 152W |
| Luminaire Output Lumen CRI>70 - 4000K | 21385lm |
| Driving Current | 700mA |
| Mast Span (a) | 22m |
| Mast Height (h) | 6m |
| Road Width (L) | 16m |
| Lighting Class | - |
| Optical Type | Maximum pole spacing |
| Armature Data | |
|---|---|
| Product Code | O07.ST.16955.152.840.05 |
| Family Name | Eagle ST |
| Material | Aluminum Injection |
| LED Life | L70/B50 50000h |
| Optical | Asymmetric Street Lighting Lens |
| Luminaire Maximum Power | 152W |
| Number of LEDs | 108 |
| Circuit | 24S2P |
| LED Type | 3535 |
| CRI | 80 |
| Operating Temperature | -20°C / +50°C |
| Protection | IP66 |
1- Product code / Armature code2- Power / Power3- CRI / Kelvin4- Color / Product color
Frequently Asked Questions
What is the wattage of Kartal ST?
Kartal ST has a power of 104-152W.
What is the protection class of Kartal ST?
The protection class of Kartal ST is IP66.
Which certifications and standards does Kartal ST have?
Kartal ST carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, Protection class II, IP66, IK08.
What is the product code of Kartal ST?
The product (stock) code of Kartal ST is O07.ST.16955.
