Gora Mini Surface
Gora Mini Surface is an AVOLUX LED lighting fixture in the Surface Mounted Series category with a power of 4W and IP66 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 4W |
| Protection Class | IP66 |
| Shape | surface mounted |
| Optical | Lens |
DESCRIPTION
-- LED projector fixture with symmetrical light output.
-- Body made of corrosion-resistant aluminum injection raw material.
-- It has a bracketed mounting system.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design.
-- Narrow, medium and very wide angle options are available.
-- 2700K, 3000K, 3500K, 4000K, 5000K and 6500K color temperature
options are available.
-- Illumination is provided up to a height of 30 meters.
-- IP protection is provided without any problems with silicone gaskets.
-- All external screws are stainless.
-- Corrosion and salt resistant thanks to double-layer polyester powder paint.
-- Efficiency up to 115lm/W.
-- High color compatibility: <3 SDCM
-- Stainless cable gland is used in the luminaire and 220V main
The mains cable has an IP68 protected connector. with this
inside the product by using the 220V cable end and the water stopper between the armature.
Humidification and water vapor formation are minimized.
-- DALI and 1-10V Dim options are available.
-- Thanks to its high cooling capacity, Gora Surface has high Ta temperature
It also works comfortably in environments with high values.
-- L80 B10 50000 hours and five years warranty.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 4W | CRI>70 | O07.SM.00727 . (..) . (...) . (..) . (..) | 2700K | 345 |
| 3000K | 348 | |||
| 3500K | 356 | |||
| 4000K | 371 | |||
| 5000K | 375 | |||
| 6500K | 363 | |||
| CRI>80 | O07.SM.00727 . (..) . (...) . (..) . (..) | 2700K | 336 | |
| 3000K | 340 | |||
| 3500K | 362 | |||
| 4000K | 368 | |||
| 5000K | 372 | |||
| 6500K | 360 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4 | 4W - 500mA | 727 | CRI>70 - 2700K | 827 | CRI>80 - 2700K |  | SP | 15° - Spot |  | 01 | white |
| 730 | CRI>70- 3000K | 830 | CRI>80 - 3000K |  | M.E. | 34° - Medium |  | 02 | ral 9010 | ||
| 735 | CRI>70- 3500K | 835 | CRI>80 - 3500K |  | FL | 50° - Flood |  | 03 | black | ||
| 740 | CRI>70- 4000K | 840 | CRI>80 - 4000K |  | 04 | gray | |||||
| 750 | CRI>70- 5000K | 850 | CRI>80 - 5000K |  | 05 | dark gray | |||||
| 765 | CRI>70 - 6500K | 865 | CRI>80 - 6500K |  | 06 | special color | |||||
1- Product code / Armature code
2- Power / Güç
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Gora Mini Surface?
Gora Mini Surface has a power of 4W.
What is the protection class of Gora Mini Surface?
The protection class of Gora Mini Surface is IP66.
Which certifications and standards does Gora Mini Surface have?
Gora Mini Surface carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IP66, IK08.
What is the product code of Gora Mini Surface?
The product (stock) code of Gora Mini Surface is O07.SM.00727.
Where can I download the catalog or PDF of Gora Mini Surface?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/589.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/S%C4%B1va%20%C3%9Cst%C3%BC/Gora%20Surface.pdf) buttons on this page.
