Deepress IP Surface
Deepress IP Surface is an AVOLUX LED lighting fixture in the Surface Mounted Series category with a power of 2x4-2x15W and IP65 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 2x4-2x15W |
| Protection Class | IP65 |
| Shape | surface mounted |
| Optical | Lens |
DESCRIPTION
-- Aluminum injection body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- Mechanical locking system with 15° movement capability in a single axis.
-- Classic DALI, 1-10V and Phase DIM options can be applied.
-- High-tech control systems Wireless DIM, Hot DIM and
Dynamic White applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
-- Only the Honeycomb Filter accessory option is applicable.
-- Narrow, Medium, Wide, Very Wide and Oval Lens angle options are available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LED
options are available.
-- Efficiency up to 121lm/W.
-- High color compatibility: <3 SDCM
-- IP65 Protection class.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 2x15W | CRI>80 | O07.MLS.84036 . (..) . (...) . (..) . (..) | 2700K | 3302 |
| 3000K | 3404 | |||
| 3500K | 3524 | |||
| 4000K | 3642 | |||
| 5000K | 3896 | |||
| CRI>90 | O07.MLS.84036 . (..) . (...) . (..) . (..) | 2700K | 2972 | |
| 3000K | 3064 | |||
| 3500K | 3200 | |||
| 4000K | 3336 | |||
| 5000K | X | |||
| CRI>98 | O07.MLS.84036 . (..) . (...) . (..) . (..) | 2700K | 2170 | |
| 3000K | 2250 | |||
| 4000K | 2410 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 15 | 2x15W - 350mA | 827 | CRI>80 - 2700K | 930 | CRI>90 - 3000K |  | SP | 20° - Spot |  | 01 | white |
| 10 | 2x10W - 250mA | 830 | CRI>80 - 3000K | 935 | CRI>90 - 3500K |  | M.E. | 35° - Medium |  | 02 | ral 9010 |
| 7 | 2x7W - 180mA | 835 | CRI>80 - 3500K | 940 | CRI>90 - 4000K |  | FL | 50° - Flood |  | 03 | black |
| 4 | 2x4W - 100mA | 840 | CRI>80 - 4000K | 9827 | CRI>98 - 2700K |  | W.F. | 70° - Wide Flood |  | 04 | gray |
| 850 | CRI>80 - 5000K | 9830 | CRI>98 - 3000K |  | OV | 20° x 60° - Oval |  | 05 | dark gray | ||
| 927 | CRI>90 - 2700K | 9840 | CRI>98 -4000K |  | 06 | special color | |||||
1- Product code / Armature code
2- Power / Güç
3- CRI / Kelvin
4- Reflector angle
5- Color / Product color
Frequently Asked Questions
What is the wattage of Deepress IP Surface?
Deepress IP Surface has a power of 2x4-2x15W.
What is the protection class of Deepress IP Surface?
The protection class of Deepress IP Surface is IP65.
Which certifications and standards does Deepress IP Surface have?
Deepress IP Surface carries the following certifications and standards: PBS, SASO, CB, LVD, EAC, CE, Protection class I, IP66, IK08.
What is the product code of Deepress IP Surface?
The product (stock) code of Deepress IP Surface is O07.MLS.84036.
Where can I download the catalog or PDF of Deepress IP Surface?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/outdoor/599.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/S%C4%B1va%20%C3%9Cst%C3%BC/Deepress%20IP%20Surface.pdf) buttons on this page.
