Cub Maxi Surface
Cub Maxi Surface is an AVOLUX LED lighting fixture in the COB Led Surface Mounted Series category with a power of 24W and IP44 protection.
Product icons
| Input Voltage | 220-240V / 50-60Hz |
|---|---|
| Wattage | 24W |
| Protection Class | IP44 |
| Shape | surface mounted |
| Optical | Reflector |
DESCRIPTION
-- Aluminum body.
-- 220-240V / 50-60Hz energy input.
-- Intelligent cooling design with passive cooling technology.
-- Tempered glass.
-- Classic DALI, 1-10V and Phase DIM options can be applied.
-- High-tech control systems Wireless DIM, Hot DIM and
Dynamic White applications can be made.
-- Standard color options: White, Black, Grey, Dark Grey, RAL9010
Additionally, optional special color options can be applied.
--Honeycomb Filter and Color Filter accessory options are applicable.
-- Narrow and Wide reflector angle options are available.
-- Standard CRI>80, high CRI>90 and extra high CRI>98 LED
options are available.
-- Efficiency up to 117lm/W.
-- High color compatibility: <3 SDCM.
-- Emergency lighting kit system can be applied.
| Strength | CRI | Order Code | Kelvin | Lumen |
|---|---|---|---|---|
| 24W | CRI>80 | I01.MLS.14026 . (..) . (...) . (..) . (..) | 2700K | 2555 |
| 3000K | 2620 | |||
| 3500K | 2710 | |||
| 4000K | 2806 | |||
| 5000K | 3002 | |||
| CRI>90 | I01.MLS.14026 . (..) . (...) . (..) . (..) | 2700K | 2324 | |
| 3000K | 2382 | |||
| 3500K | 2466 | |||
| 4000K | 2553 | |||
| 5000K | X | |||
| CRI>98 | I01.MLS.14026 . (..) . (...) . (..) . (..) | 2700K | 1785 | |
| 3000K | 1850 | |||
| 4000K | 1981 |
| 2 | Watts - Driving Current | 3 | CRI/Kelvin | 3 | CRI/Kelvin | 4 | Reflector Angle | 5 | Product Color | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 24 | 24W - 600mA | 827 | CRI>80 - 2700K | 930 | CRI>90 - 3000K |  | SP | 20° - Spot |  | 01 | white |
| 20 | 20W - 500mA | 830 | CRI>80 - 3000K | 935 | CRI>90 - 3500K |  | FL | 40° - Flood |  | 02 | ral 9010 |
| 15 | 15W - 350mA | 835 | CRI>80 - 3500K | 940 | CRI>90 - 4000K |  | 03 | black | |||
| 10 | 10W - 250mA | 840 | CRI>80 - 4000K | 9827 | CRI>98 - 2700K |  | 04 | gray | |||
| 850 | CRI>80 - 5000K | 9830 | CRI>98 - 3000K |  | 05 | dark gray | |||||
| 927 | CRI>90 - 2700K | 9840 | CRI>98 -4000K |  | 06 | special color |
- Luminaire code
- Strength
- Kelvin
- Reflector Angle
- Product Color
Frequently Asked Questions
What is the wattage of Cub Maxi Surface?
Cub Maxi Surface has a power of 24W.
What is the protection class of Cub Maxi Surface?
The protection class of Cub Maxi Surface is IP44.
Which certifications and standards does Cub Maxi Surface have?
Cub Maxi Surface carries the following certifications and standards: SASO, CB, LVD, EAC, CE, Protection class I, IP44.
What is the product code of Cub Maxi Surface?
The product (stock) code of Cub Maxi Surface is I01.MLS.14026.
Where can I download the catalog or PDF of Cub Maxi Surface?
You can download it with the 'DOWNLOAD PRODUCT PDF' (https://avolux.com/media/pdf/580.pdf), 'DOWNLOAD PRODUCT FAMILY PDF' (https://avolux.com/media/downloads/surface/CUB%20Surface.pdf), 'DOWNLOAD LDT' (https://avolux.com/media/downloads/LDT/indoor/Cub%20MaxiI01.MLS.14026.rar) buttons on this page.
